OPzS cells pair tubular positive plates with a free liquid (flooded) electrolyte in a transparent-style stationary case. The construction is older than its sealed sibling and unashamed of it: in exchange for periodic watering and a vented battery room, OPzS delivers the lowest purchase cost per cycle of any lead acid design, with electrolyte you can inspect, test with a hydrometer and top up — total visibility into the battery’s state of health. XD Battery documents two OPzS solar models: the 2V 500Ah cell (26 kg, 166 × 206 × 470 mm) and the 2V 1000Ah cell (53.5 kg, 233 × 210 × 645 mm), both with a three-year warranty and OEM/ODM availability.
The documented applications are solar and stationary storage, where OPzS has served for generations: off-grid power houses, village electrification, railway and utility standby with attended maintenance regimes. If your site has staff who will water cells on schedule, OPzS’s economics are hard to beat; if the site is unmanned, the sealed OPzV page is your page.
| Model | OPzS 2V 500Ah Solar Battery |
|---|---|
| Nominal voltage / capacity | 2V / 500Ah |
| Weight | 26 kg |
| Dimensions | 166 × 206 × 470 mm |
| Warranty | 3 years |
| Model | OPzS 2V 1000Ah Solar Battery |
|---|---|
| Nominal voltage / capacity | 2V / 1000Ah |
| Weight | 53.5 kg |
| Dimensions | 233 × 210 × 645 mm |
| Warranty | 3 years |
The maintenance contract, honestly
Budget for it at purchase: distilled water top-ups on a schedule set by your float voltage and temperature, terminal care, and periodic specific-gravity readings — which are also OPzS’s gift, since state of health is directly measurable rather than inferred. Sites that keep the routine get the design life; sites that cannot should buy sealed.
OPzS or OPzV for an unmanned solar site?
OPzV. Flooded cells need watering; unmanned sites are where gel earns its premium.
Can OPzS cells be mixed into an existing string?
Only as a matched, same-age replacement policy allows — in practice, strings are renewed as sets. Tell us the existing string’s age and model when inquiring.
